Continuous Stirred Tank Reactor

Product Code : JA-CR-9130
Jaincolab is a leading Continuous Stirred Tank Reactor Manufacturer,and suppliers in India, Continuous Stirred Tank Reactor Manufacturer,and suppliers in South Africa, Continuous Stirred Tank Reactor Algeria (Algiers), Continuous Stirred Tank Reactor Angola (Luanda), Continuous Stirred Tank Reactor Argentina (Buenos Aires), Continuous Stirred Tank Reactor Armenia (Yerevan), Continuous Stirred Tank Reactor Australia (Canberra), Continuous Stirred Tank Reactor Austria (Vienna), Bahrain (Manama), Bangladesh (Dhaka), Bhutan (Thimphu), Bolivia (Sucre), Botswana (Gaborone), Brazil (Brasília), Brunei (Bandar Seri Begawan), Montenegro (Podgorica), Morocco (Rabat), Mozambique (Maputo), Myanmar (Naypyidaw), Namibia (Windhoek), Nepal (Kathmandu), New Zealand (Wellington), Nigeria (Abuja), Oman (Muscat), Palestine (Ramallah), Panama (Panama City), Papua New Guinea (Port Moresby), Paraguay (Asunción), Peru (Lima), Philippines (Manila)¸ Portugal (Lisbon), Qatar (Doha), Rwanda (Kigali), Saudi Arabia (Riyadh), Senegal (Dakar), Serbia (Belgrade), Sierra Leone (Freetown), Slovakia (Bratislava), South Africa (Cape Town) (Pretoria) (Bloemfontein), South Sudan (Juba), Spain (Madrid), Sri Lanka (Sri Jayawardenepura Kotte) (Colombo), Sudan (Khartoum), Syria (Damascus), Tanzania (Dodoma), Thailand (Bangkok), Togo (Lomé), Tonga (Nuku'alofa), Trinidad and Tobago (Port of Spain), Tunisia (Tunis), Turkey (Ankara), Turkmenistan (Ashgabat), Uganda (Kampala), United Arab Emirates (Abu Dhabi), United Kingdom (London), United States (Washington, D.C.).

Continuous Stirred Tank Reactor
Description:-
An ideal steady state flow reactor the contents in the reactor are well mixed and have a uniform composition throughout.
The exit stream has the same composition as the fluid within the reactor.
This type of reactor is known as mixed flow reactor.
The flow rate can be adjusted by operating the needle valves provided on respective Rotameter.
The compressed air is used for circulation of feed.
JAab CSTR is fitted with a stirrer for proper mixing.
This set-up is used to study a non-catalytic homogeneous second order liquid phase reaction under ambient condition.
From the top outlet of it, samples are collected for analysis.
Pressure Regulator, Pressure Gauge, and Safety Valve are fitted in the compressed air line.
The set up consists of two feed tanks through which two reactants are fed to the reactor.
Rotameters are provided to measure the individual flow of Chemicals.

Experimentation:-
To study the progress of a suitable Chemical Reaction Engineering Lab Equipments CSTR.
To determine the Reaction Rate Constant.

Utility Required:-
Compressed Air Supply at 1 HP, 2 CFM.
Drain.
Electricity Supply: 1 Phase, 220 VAC, 0.5 kW.
Water Supply.
Instruments, Laboratory Glassware, and Chemicals required for analysis as per the system adopted.

Technical Detail:-
Feed Tank: Material Stainless Steel.
Capacity - 20 Ltrs.
Feed Circulation: By compressed air.
Flow Measurement: Rotameter 2Nos.
Pressure Regulator: 0-2 Kg/cm2
Reactor: Material Stainless Steel, Capacity 2 Ltrs (Approx).
Stirrer: Stainless Steel Impeller and shaft coupled with FHP Motor.
Pressure Gauge: Bourdon type 0-2 Kg/cm2
Stop Watch: Electronic
Control Panel comprises of Standard make the on-off switch, Mains Indicator etc.
Piping: Stainless Steel and PVC.
