Adapters - Multiple, Two Parallel and One 45 Degree Neck Manufacturer,Supplier and Exporter in India
Product Code : JA-LAOK-1560
The Adapters - Multiple, Two Parallel and One 45 Degree Neck (product code JA-LAOK-1560) is a three-neck multiple adapter. A single ground-glass cone fits the socket of a single-neck flask, and the head above it carries two parallel socket necks and a third neck angled at 45 degrees. This gives a plain flask three openings for a condenser, a dropping funnel and a thermometer or gas line. It is listed with a B24 or B29 cone and B19 sockets.
Specifications
The adapter carries one ground-glass cone and three ground-glass socket necks: two parallel to the cone and one at 45 degrees. Two combinations are listed, B24/B19 and B29/B19, meaning a B24 or B29 cone with B19 socket necks.
| Product | Adapters - Multiple, Two Parallel and One 45 Degree Neck |
| SKU / Product code | JA-LAOK-1560 |
| Type | Multiple adapter, two parallel necks and one 45 degree neck |
| Joints | One ground-glass cone, three ground-glass socket necks, B-series |
| Neck arrangement | Two necks parallel to the cone, one at 45 degrees |
| Cone / socket combinations listed | B24/B19, B29/B19 |
Applications of the three-neck multiple adapter
This adapter lets a laboratory run three-opening set-ups on ordinary single-neck flasks, which is useful where three-neck flasks are not stocked in every size.
- Reflux with controlled addition: condenser, dropping funnel and thermometer on one flask
- Reactions under an inert gas with a gas inlet on the angled neck
- Preparative organic chemistry in B.Sc. and M.Sc. practicals
- Research set-ups built from single-neck round-bottom flasks
Scope of supply and ordering
The listing covers one multiple adapter with two parallel necks and one 45 degree neck, with either a B24 or a B29 cone and B19 sockets.
Frequently asked questions
Which cone sizes are listed?
Two versions are listed: a B24 cone and a B29 cone, both with B19 socket necks.
What can be fitted to the three necks?
Any apparatus with a B19 cone, for example a condenser, a dropping funnel, a thermometer adapter or a gas inlet adapter.
Is a two-neck version available?
Yes. The range lists a multiple adapter with two necks and one with one parallel and one 45 degree neck.
