Manometer Open U-Tube Manufacturer,Supplier and Exporter in India
Product Code : JL-LEP-10268
The Manometer Open U-Tube (SKU JL-LEP-10268) is a differential pressure manometer: a U-shaped glass tube partly filled with liquid, with no moving parts and no calibration needed. One arm is 50 cm long with a funnel top; the other is a 4.5 cm arm bent at 90 degrees with a 15 mm rifted tip for tubing. The open U-tube manometer is mounted on a 540 x 90 mm board on a wooden stand, with a millimetre scale from 0 to 50 cm between the arms. JaincoLab supplies it with 3 m of latex tubing, as per DepEd guidelines.
Specifications
The manometer is specified by type, arms, mounting and scale: a glass differential U-tube with a 50 cm funnel-top arm and a 4.5 cm arm bent at 90 degrees, a 540 x 90 mm back plate on a wooden stand, and a 0-50 cm scale in 1 mm steps.
| Product | Manometer Open U-Tube |
| SKU | JL-LEP-10268 |
| Type | Differential pressure manometer |
| Construction | U-shaped glass tube, partly filled with liquid, no moving parts, no calibration required |
| Arms | 50 cm arm with funnel top; 4.5 cm arm bent at 90 degrees with 15 mm rifted tip |
| Mounting | Board fixed on a wooden stand for vertical mounting |
| Back plate | 540 mm x 90 mm |
| Scale | Millimetre scale between the arms, 0 - 50 cm, 1 mm increments, zero at the bottom |
| Latex tubing | 8 mm ID, non-toxic, non-tacky latex, 3 m |
| Specification reference | As per DepEd guidelines |
Applications of the open U-tube manometer
The manometer is used in pressure lessons to measure differences in gas or liquid pressure. Typical uses are:
- Measuring gas pressure above or below atmospheric
- Showing how liquid pressure changes with depth using a probe
- Measuring lung pressure by gently blowing through the tubing
- Comparing pressures in simple fluid experiments
Scope of supply and ordering
Each unit is one U-tube manometer on its board and stand with 3 m of latex tubing. Pressure probes and liquids are separate.
MOQ, packing and lead time for manometers are confirmed on each quotation for the quantity and destination, with the glass tube packed for transit.
Frequently asked questions
What type of manometer is this?
A glass open U-tube differential pressure manometer with no moving parts.
What is the scale range?
0 to 50 cm in 1 mm increments, with zero at the bottom.
Is tubing included?
Yes. 3 m of non-toxic, non-tacky latex tubing.
