Variac Single & Three Phase Manufacturer,Supplier and Exporter in India
Product Code : JA-SI-8148
The Variac Single and Three Phase (SKU JA-SI-8148) is a variable voltage autotransformer for setting a smooth, continuously adjustable AC supply on the bench. A knob turns the output, which is read on a calibrated dial on top. On line voltage connection the output runs from 0 to 240 V, and on the over-voltage connection from 0 to 270 V. The unit sits in a thick metal box with air vents for cooling.
Specifications
The listing gives:
| Product | Variac Single & Three Phase |
| SKU | JA-SI-8148 |
| Phases | Single phase or three phase |
| Output voltage | 0-240 V (line connection), 0-270 V (over-voltage connection) |
| Control | Knob with calibrated dial on top |
| Input | Mains cable |
| Output terminals | Insulated 4 mm sockets and 3-pin 15 A socket |
| Indicator | On/Off |
| Protection | Slow-blow fuse in the output line |
| Enclosure | Thick metal box with air vents |
| Current rating | As per requirement |
Scope of supply and ordering
The current capacity and the single- or three-phase version are chosen at enquiry; quantities and packing are confirmed on the quotation.
Frequently asked questions
What output voltage does the variac give?
0-240 V on the line voltage connection and 0-270 V on the over-voltage connection.
How is the output taken?
Through insulated 4 mm sockets and a 3-pin 15 A socket, with a slow-blow fuse in the output line.
