Advanced Electromagnetism Kit Manufacturer,Supplier and Exporter in India
Product Code : JL-LEP-10347
The Advanced Electromagnetism Kit (SKU JL-LEP-10347) is a set of magnets, compasses, a magnetic field mapper, magnet wire and hardware for demonstrating the relationship between electricity and magnetism. With this electromagnetism kit students map magnetic field lines, wind a coil on the steel rod to make an electromagnet and observe compass deflection near a current-carrying wire. JaincoLab manufactures it in India for secondary-school physics and general science laboratories.
Specifications
The electromagnetism kit contains two 150 mm bar magnets, two 100 mm U-magnets with a 50 mm jaw, six 20 mm compasses, a 9 × 16 cm magnetic field mapper, a 500 g spool of #20 gauge magnet wire, a 12 mm steel rod, two insulated #14 gauge copper wires and three drilled wood blocks.
| Product | Advanced Electromagnetism Kit |
| SKU | JL-LEP-10347 |
| Purpose | Demonstrates the relationship between electricity and magnetism |
| Bar magnets | 2 pieces, 150 mm × 12 mm × 8 mm; magnet strength 2 times its weight; labelled/colour-coded North and South poles |
| Magnetic compass | 6 pieces, 20 mm diameter, correct orientation |
| U-magnets | 2 pieces, 6 mm × 16 mm cross-section × 100 mm long, 50 mm jaw opening; magnet strength 2 times its weight; labelled/colour-coded North and South poles |
| Magnetic field mapper | 1 piece, 9 cm × 16 cm clear transparent casing with iron filings in a non-mould-forming viscous liquid; clearly shows magnetic lines |
| Magnet wire | 1 spool, insulation-coated, #20 gauge, 500 g |
| Steel rod | 1 piece, 12 mm diameter × 100 mm long |
| Copper wire | 2 pieces, solid, #14 gauge, insulated, 15 cm long each |
| Wood blocks | 3 pieces, 25 mm × 75 mm × 100 mm, with pilot holes through the centre of each block |
| Specification reference | As per DepEd guidelines |
Applications of the electromagnetism kit
The kit is used for a sequence of magnetism and electromagnetism activities, starting with the poles and field of permanent magnets and moving on to the magnetic effect of an electric current, in secondary-school physics and general science classes.
- Identifying North and South poles and testing attraction and repulsion with the colour-coded bar and U-magnets
- Mapping the field lines of bar and U-magnets with the magnetic field mapper and the six compasses
- Winding the magnet wire on the steel rod to build a simple electromagnet
- Showing the magnetic field around a current-carrying copper wire with the compasses
- Mounting coils and wires on the drilled wood blocks for classroom demonstrations
Scope of supply and ordering
The listing covers the kit contents given in the specification table: magnets, compasses, field mapper, magnet wire, steel rod, copper wire and wood blocks. A power source is not in the listed contents.
Frequently asked questions
What is in the Advanced Electromagnetism Kit?
Two bar magnets, six magnetic compasses, two U-magnets, a magnetic field mapper, a spool of magnet wire, a steel rod, two copper wires and three wood blocks.
How strong are the magnets?
The bar magnets and U-magnets each have a magnet strength of 2 times their weight and labelled or colour-coded North and South poles.
How does the magnetic field mapper work?
It is a 9 cm × 16 cm clear casing with iron filings in a viscous liquid that clearly shows magnetic lines.
Is a battery or power supply included?
A power source is not in the listed kit contents. Dry cells and cell holders are listed separately and can be quoted with the kit.
