Mechanical Drive Systems Manufacturer,Supplier and Exporter in India
Product Code : JA-MWLE-9478
The Mechanical Drive Systems trainer (SKU JA-MWLE-9478) is a mechanical drives training system for teaching the operation, installation, performance analysis and basic design of power transmission systems. Learners assemble and test drives built from chains, V-belts, spur gears, bearings and couplings on a mobile workstation, loading them with a prony brake. This mechanical drives trainer is supplied by JaincoLab for ITI, polytechnic and engineering college maintenance and mechanical laboratories.
Specifications
The listed system includes a mobile workstation, a motor control unit, mechanical transmission components, specialised tools, a prony brake load device and performance measurement instruments; motor rating, dimensions and component counts are confirmed on the quotation.
| Product | Mechanical Drive Systems |
| SKU | JA-MWLE-9478 |
| Type | Mechanical drives training system |
| Included (as listed) | Mobile workstation, motor control unit, mechanical transmission components, specialised tools, prony brake load device, performance measurement instruments |
| Drive elements | Chains, V-belts, spur gears, bearings, couplings |
| Topics | Key fasteners, power transmission, V-belt drives, chain drives, spur gear drives, multiple shaft drives |
Applications of the mechanical drives trainer
Students install, align and load belt, chain and gear drives on the workstation, then use the measuring instruments and prony brake to compare drive performance.
- Installing and aligning V-belt, chain and spur gear drives
- Measuring drive performance under load with the prony brake
- Studying key fasteners, couplings and bearings in power transmission
- Designing simple multiple-shaft drives
- Maintenance fitter and millwright training in ITIs and polytechnics
Scope of supply and ordering
This listing covers the mechanical drives training system with the items listed in the specification table. Accessories, spares and quantities are confirmed on the quotation. Curriculum material, spares and electrical supply details are also confirmed on the quotation.
Packing, lead time and any minimum order for the Mechanical Drive Systems are confirmed per quotation according to order size and destination. Bulk orders for training institutes are supplied, and export consignments to buyers in Africa, the Middle East and South and South-East Asia are quoted on request.
Frequently asked questions
What does the trainer include?
A mobile workstation, motor control unit, transmission components, specialised tools, a prony brake load device and performance measurement instruments.
Which drive types can be studied?
V-belt, chain and spur gear drives, with bearings, couplings and multiple shaft arrangements.
How are the drives loaded?
With the prony brake load device supplied in the system.
