Single Phase Half Controlled Symmetrical Manufacturer,Supplier and Exporter in India
Product Code : JA-PET-1431
Jaincolab is a leading Single Phase Half Controlled Symmetrical Manufacturer,and suppliers in India
Single Phase Half Controlled Symmetrical
- Power Electronic Training Board has been designed specifically to study and obtain the waveforms for single phase half controlled symmetrical & asymmetrical bridge converter.
- Practical experience on this board carries great educative value for Science and Engineering Students.
Object:
- To study and obtain the single phase half controlled symmetrical bridge converter.
- To study and obtain the single phase half controlled asymmetrical bridge converter.
Features:
The board consists of the following built-in parts:
- An isolation transformer 230VA.C. at 200mA. This protects external instruments for damage if they are not isolated
- 6VAC at 100mAAC Power Supply
- ±12V DC at 100mA fixed regulated Power Supply
- Two Op-Amp’s. IC
- Quad, Ex-OR gate IC
- Triple, 3 input AND gate IC
- Hex inverter gate IC
- Quad, two input AND gate IC
- Three NPN Transistor
- Two SCR’s
- Potentiometer for reference voltage adjustment
- Two Pulse Transformer 1:1
- 40 watt bulb
- Adequate no. of other Electronic Components
- Mains ON/OFF switch, Fuse and Jewel light
- The unit is operative on 230V ±10% at 50Hz A.C. Mains
- Adequate no. of patch cords stackable 4 mm spring loaded plug length ½ metre
- Good Quality, reliable terminal/sock ets are provided at appropriate places on panel for connections/observation of waveforms
- Strongly supported by detailed Operating Instructions, giving details of Object, Theory, Design procedures, Report Suggestions and Book References
Weight:
- 7 Kg. (Approx.)
Dimension:
- W 412 x H 150 x D 310
Other Apparatus Required:
- Dual Trace Cathode Ray Oscilloscope 20MHz (Unearthed)
