Study of 16-1 Sixteen input and one output Multiplexer using IC-74150 Manufacturer,Supplier and Exporter in India
Product Code : JA-DEECP-1186
The Jaincolab Study of 16-1 Sixteen Input and One Output Multiplexer using IC-74150 is a digital electronics trainer built around the industry-standard 74150 16-line to 1-line data selector/multiplexer IC. It lets students route any one of sixteen data inputs to a single output using a 4-bit binary select code, and verify the active-low strobe/enable control that switches the output on or off. It is manufactured and supplied by Jaincolab, a scientific instrument manufacturer based in Ambala, Haryana, for engineering and polytechnic institutions across India and internationally.
What This 16-to-1 Multiplexer States
| Parameter | Description |
|---|---|
| IC Used | 74150, a 16-line to 1-line data selector/multiplexer |
| Data Inputs | 16 inputs (D0 to D15) |
| Select Lines | 4 binary select lines (S0 to S3), addressing one of 16 inputs |
| Output | 1 active-low output (W) |
| Strobe / Enable | Active-low strobe input; output is disabled when strobe is inactive |
| Logic Family | TTL (Transistor-Transistor Logic) |
Key Features
- Demonstrates 16-to-1 multiplexer operation using the industry-standard 74150 TTL IC
- Allows verification of select-line combinations against the multiplexer truth table
- Illustrates the function of the active-low strobe/enable control on the IC
- Switch inputs for data and select lines, with direct output verification
- Manufactured by Jaincolab for engineering, polytechnic and diploma digital electronics laboratories
Why Choose Jaincolab
Jaincolab is a direct manufacturer of digital electronics trainer kits, not a reseller, supplying engineering and polytechnic institutions across India and internationally. This trainer sits alongside related data-selector and multiplexer trainers in the same range, including the Study of 2-1 Multiplexer using AND, OR and NOT Gates and the wider Digital Electronics Trainer range, all part of Jaincolab's broader Scientific Instrument range for engineering and applied-physics laboratories.
Applications
| Setting | Typical Use |
|---|---|
| Engineering / polytechnic digital electronics lab | Verifying 16-to-1 multiplexer truth table and IC pin functions |
| Computer science / computer principles lab | Teaching data routing and address decoding concepts using select lines |
| Diploma electronics workshop | Hands-on wiring and testing practice with TTL data-selector ICs |
Frequently Asked Questions
Q: What does this trainer demonstrate?
A: It demonstrates a 16-to-1 multiplexer built around the 74150 IC, letting students route any one of sixteen data inputs to a single output using a 4-bit select code and an active-low strobe control.
Q: What is the role of the select lines?
A: The four select lines (S0 to S3) form a binary address that determines which one of the sixteen data inputs is connected to the output.
Q: Is this trainer suitable for engineering and polytechnic laboratories?
A: Yes, it is designed for engineering, polytechnic and diploma-level digital electronics laboratory courses covering combinational logic and data-selector circuits.
Q: What certification does Jaincolab hold for its manufacturing?
A: Jaincolab holds ISO 9001:2015 (quality management) and ISO 14001:2015 (environmental management) certification for its manufacturing operations.
Q: How can I get a quotation for this trainer?
A: Share the quantity required and your delivery destination with Jaincolab's sales team, and a quotation will be issued for this trainer along with any related digital electronics trainers you need.
Request a Quote
For pricing, bulk orders or technical questions on the Study of 16-1 Sixteen Input and One Output Multiplexer using IC-74150, contact Jaincolab's team with your item list, quantities and delivery destination.
