Training Board for Triac

Product Code : JA-AET-1461
Jaincolab is a leading Training Board for Triac Manufacturer,and suppliers in India, Training Board for Triac Manufacturer,and suppliers in South Africa, Training Board for Triac Algeria (Algiers), Training Board for Triac Angola (Luanda), Training Board for Triac Argentina (Buenos Aires), Training Board for Triac Armenia (Yerevan), Training Board for Triac Australia (Canberra), Training Board for Triac Austria (Vienna), Bahrain (Manama), Bangladesh (Dhaka), Bhutan (Thimphu), Bolivia (Sucre), Botswana (Gaborone), Brazil (Brasília), Brunei (Bandar Seri Begawan), Montenegro (Podgorica), Morocco (Rabat), Mozambique (Maputo), Myanmar (Naypyidaw), Namibia (Windhoek), Nepal (Kathmandu), New Zealand (Wellington), Nigeria (Abuja), Oman (Muscat), Palestine (Ramallah), Panama (Panama City), Papua New Guinea (Port Moresby), Paraguay (Asunción), Peru (Lima), Philippines (Manila)¸ Portugal (Lisbon), Qatar (Doha), Rwanda (Kigali), Saudi Arabia (Riyadh), Senegal (Dakar), Serbia (Belgrade), Sierra Leone (Freetown), Slovakia (Bratislava), South Africa (Cape Town) (Pretoria) (Bloemfontein), South Sudan (Juba), Spain (Madrid), Sri Lanka (Sri Jayawardenepura Kotte) (Colombo), Sudan (Khartoum), Syria (Damascus), Tanzania (Dodoma), Thailand (Bangkok), Togo (Lomé), Tonga (Nuku'alofa), Trinidad and Tobago (Port of Spain), Tunisia (Tunis), Turkey (Ankara), Turkmenistan (Ashgabat), Uganda (Kampala), United Arab Emirates (Abu Dhabi), United Kingdom (London), United States (Washington, D.C.).

Training Board for Triac

Object:

To study the gate characteristics of a TRIAC in the following modes:

  • Mode I+ : i.e. T2 positive with respect to T1 and gate positive with respect to T 1
  • Mode I- : i.e. T2 positive with respect to T1 and gate negative with respect to T 1
  • Mode III+ : i.e. T2 negative with respect to T1 and gate positive with respect to T 1
  • Mode III- : i.e. T2 negative with respect to T1 and gate negative with respect to T 1

To study the terminal characteristics of a TRIAC in the following modes:

  • Mode I+ : i.e. T2 positive with respect to T1 and gate positive with respect to T 1
  • Mode III+ : i.e. T2 negative with respect to T1 and gate positive with respect to T 1

To study the following applications of TRIAC:

  • Triac as a static switch (D.C. control)
  • Control of A.C. with A.C. signal
  • To measure the holding current of IH. Triac

Feature:

The board consists of following built-in parts:

  • 0-70 V D.C. at 100 mA, regulated Power Supply
  • 0-3V D.C. at 30 mA, regulated Power Supply
  • 55 Volt at 100 mA, fixed A.C. Supply
  • 7 Volt at 30 mA, fixed A.C. Supply
  • TRIAC
  • Three Potentiometers
  • Reset switch
  • Adequate no. of other electronic components
  • Mains ON/OFF switch, Fuse and Jewel light
  • The unit is operative on 230 V ±10% at 50 Hz A.C. Mains
  • Adequate no. of patch cords stackable from rear both ends 4 mm spring loaded plug length ½ metre
  • Good Quality, reliable terminal/sockets are provided at appropriate places on panel for connections / observation of waveforms
  • Strongly supported by detailed Operating Instructions, giving details of Object, Theory, Design procedures, Report Suggestions and Book References

Other Apparatus Required:

  • Cathode Ray Oscilloscope 20 MHz
  • Digital Current meter DC 3½ Digit having Dual range of 20 mA / 200 mA
  • Digital Voltmeter DC 3½ Digit having Dual range of 2 V / 200 V
  • Digital Current meter DC 3½ Digit range of 200 mA
