Boiler Heating Batching Process Control System

• This complete and comprehensively equipped laboratory test stand offers numerous possible experiments from the areas of process control.
• It contains a total of four different control loops with local digital, industrial controllers.
• In addition, it is also possible to realise two cascade control systems.
• A further controller is provided for cascade control.
• The controllers can be configured independently of each other as required and can be operated both individually and simultaneously.
• They all have serial interfaces.
• The experimental section is formed by a closed water circuit.
• Water is pumped from a supply tank through a pipe system by a 1.1 kW centrifugal pump.
• A pneumatically actuated control valve included in this circuit makes allows to change the flow rate and thus to control the circuit.
• The level can be controlled in two stainless steel tanks of differing capacity.
• For this purpose, a bypass mounted on the tank feed is controlled by a further pneumatic valve.
• The two tanks can be connected together to change the character of the control loop.
• An electronically adjustable 7.5 kW heater enables to heat the water as part of a temperature control system.
• During overheating, a siren and an alarm lamp will be activated.
• The system water in the circuit can be cooled by a heat exchanger.
• Freshwater from an external water supply is used as the cooling liquid.
• The pressure control system uses external compressed air at one of the two tanks.
• The test stand is built using only industrial standard components to increase its relevance to practice.
• The support made of steel tubes is fitted with laboratory castors and can thus be easily moved around.
• Software for the process visualization and Profibus card are available as an accessory.
