Gear Trains Apparatus Manufacturer,Supplier and Exporter in India
Product Code : JA-AMLE-8939
The Gear Trains Apparatus (SKU JA-AMLE-8939) is a self-contained, bench-mounted gear train apparatus for studying simple and compound gear trains and simple epicyclic gearing. It is supplied with 40, 60, 80 and 100 tooth gears and an additional rotating arm for the epicyclic arrangement, and the base has a drawer to hold all gears, spacers and pins. It is manufactured by JaincoLab for applied mechanics and theory of machines labs.
Specifications
The bench unit is supplied with 40, 60, 80 and 100 tooth gears, a rotating arm for simple epicyclic gearing and a storage drawer, and measures about 290 x 125 x 120 mm at 2.2 kg.
| Product | Gear Trains Apparatus |
| SKU | JA-AMLE-8939 |
| Type | Self-contained bench-mounted unit |
| Gears supplied | 40, 60, 80 and 100 tooth |
| Epicyclic | Additional rotating arm for simple epicyclic gearing |
| Storage | Base drawer for gears, spacers and pins |
| Manual | Instruction manual for student and lecturer |
| Dimensions and weight | 290 x 125 x 120 mm; 2.2 kg (approx.) |
Applications of the gear train apparatus
Students assemble gears of different sizes to measure velocity ratio and direction of rotation, then add the rotating arm to see how an epicyclic train produces its ratio.
- Velocity ratio of simple gear trains
- Compound gear trains
- Effect of an idler gear on direction
- Simple epicyclic gearing with the rotating arm
- Applied mechanics and theory of machines practicals in B.Tech and diploma courses
Scope of supply and ordering
The listing covers the gear trains apparatus with 40, 60, 80 and 100 tooth gears, the epicyclic arm, spacers and pins in the base drawer, and the instruction manual. Accessories, spares and quantities are confirmed on the quotation.
Each quotation confirms the MOQ, lead time and packing for this item against the quantity ordered and the delivery destination. Orders for a single laboratory as well as multi-laboratory sets for new institutions are supplied.
Frequently asked questions
Which gears are supplied?
40, 60, 80 and 100 tooth gears.
Can it show epicyclic gearing?
Yes. An additional rotating arm is supplied for simple epicyclic gearing.
Where are the parts stored?
In a drawer fitted in the base, holding gears, spacers and pins.
Related products
- Cam and Follower Apparatus
- Flywheel Apparatus
- Winch Crab Single/Double Purchase
- Wall Mounted Screw Jack
See the complete mechanical engineering laboratory range for engineering colleges, polytechnics and ITIs.
Request a quote
Request the price and specification sheet for the Gear Trains Apparatus through the JaincoLab contact page; mention SKU JA-AMLE-8939, the quantity and where it is to be delivered. Institutions and contractors buying under a tender can also reach us via the tenders page.
