Variable Force Apparatus Manufacturer,Supplier and Exporter in India
Product Code : JA-AMLE-8938
The Variable Force Apparatus (SKU JA-AMLE-8938) is a free-standing bench-top unit that determines the work done by a vertical variable effort and compares it with the work done in lifting a load. A suspension cord carries a loaded trolley at mid-span; the cord is clamped at one end and the tensioning effort is applied vertically at the other. This variable force apparatus is manufactured by JaincoLab for applied mechanics labs in engineering colleges and polytechnics.
Specifications
The bench-top unit measures 585 x 130 x 635 mm and weighs 3.2 kg without weights; it is supplied with a set of weights, a 1 m ruler, ball-bearing pulleys and an instruction manual for student and lecturer.
| Product | Variable Force Apparatus |
| SKU | JA-AMLE-8938 |
| Type | Free-standing bench-top unit |
| Arrangement | Suspension cord carrying a loaded trolley at mid-span; cord clamped at one end, effort applied vertically at the other |
| Pulleys | All with ball bearings |
| Supplied with | Set of weights; 1 m ruler; instruction manual for student and lecturer |
| Dimensions (excluding weights) | 585 x 130 x 635 mm |
| Weight (excluding weights) | 3.2 kg |
Applications of the variable force apparatus
The apparatus shows students that the work done by a changing effort, found from the area under a force-distance graph, equals the work done in raising the load.
- Work done by a variable force
- Force-distance graph and area under the curve
- Comparison with work done in lifting a load
- Energy conservation in a simple system
- Applied mechanics practicals in B.Tech, diploma and B.Sc courses
Scope of supply and ordering
The listing covers the bench-top unit with trolley, cord, ball-bearing pulleys, a set of weights, a 1 m ruler and the instruction manual. Accessories, spares and quantities are confirmed on the quotation.
Packing, lead time and minimum order quantity depend on the quantity and delivery destination and are confirmed on each quotation. Institutional, bulk and tender orders are supplied, including export orders to Africa, the Middle East and South and South-East Asia.
Frequently asked questions
What does the apparatus measure?
The work done by a vertical variable effort, compared with the work done in lifting a load.
What is supplied with it?
A set of weights, a 1 m ruler and an instruction manual for student and lecturer.
How large is it?
585 x 130 x 635 mm and 3.2 kg, excluding the weights.
Related products
Browse the full mechanical engineering lab equipment range from JaincoLab, covering strength of materials, metrology, machine dynamics and workshop equipment.
Request a quote
For a quotation on the Variable Force Apparatus (SKU JA-AMLE-8938), use the JaincoLab enquiry page with the number of units required and the delivery destination. Buying under a laboratory tender? Use our tenders page.
