Wall Mounted Screw Jack Manufacturer,Supplier and Exporter in India
Product Code : JA-AMLE-8943
The Wall Mounted Screw Jack (SKU JA-AMLE-8943) is a wall-mounted screw jack apparatus for comparing the efficiencies of square and V-form screws with 24 mm x 3 mm pitch threads. A 200 mm diameter turntable is rotated by two diametrically opposed cords with vertical load hangers, and the load hanger hangs by a yoke from the selected nut, so effort can be applied to raise or lower the load. It is manufactured by JaincoLab for applied mechanics labs.
Specifications
The apparatus has square and V-form screws of 24 mm x 3 mm pitch, a 200 mm turntable driven by two opposed cords, and measures 320 x 230 x 240 mm at about 9 kg excluding weights.
| Product | Wall Mounted Screw Jack |
| SKU | JA-AMLE-8943 |
| Mounting | Wall mounted |
| Screws | Square and V-form, 24 mm x 3 mm pitch threads |
| Effort | 200 mm diameter turntable rotated by two diametrically opposed cords with vertical load hangers |
| Load | Load hanger suspended by a yoke from the selected nut |
| Manual | Instruction manual for student and lecturer |
| Dimensions and weight (excluding weights) | 320 x 230 x 240 mm; 9.0 kg (approx.) |
Applications of the screw jack apparatus
Students raise a load with each screw form and compare effort, velocity ratio and efficiency, seeing why square threads are preferred for power screws and why a jack does not run back.
- Efficiency of square and V-thread screws
- Velocity ratio and mechanical advantage
- Effort to raise and to lower a load
- Self-locking condition of a screw jack
- Applied mechanics practicals in B.Tech, diploma and ITI courses
Scope of supply and ordering
The listing covers the wall-mounted screw jack apparatus with both screw forms, turntable, cords and load hangers, and the instruction manual. A set of weights is confirmed on the quotation. Accessories, spares and quantities are confirmed on the quotation.
Each quotation confirms the MOQ, lead time and packing for this item against the quantity ordered and the delivery destination. Orders for a single laboratory as well as multi-laboratory sets for new institutions are supplied.
Frequently asked questions
Which screw forms can be compared?
Square and V-form screws with 24 mm x 3 mm pitch threads.
How is the effort applied?
Through a 200 mm turntable rotated by two diametrically opposed cords with load hangers.
Can the load be lowered as well as raised?
Yes. Effort can be applied to raise or lower the load.
