Machine Friction of Belts Apparatus Manufacturer,Supplier and Exporter in India
Product Code : JA-AMLE-8944
The Machine Friction of Belts Apparatus (SKU JA-AMLE-8944) is a wall-mounted belt friction apparatus consisting of a pulley, three belts and two load hangers. The aluminium alloy pulley, about 150 mm in diameter and graduated at 15 degree intervals, has machined grooves to suit V, rope and flat belts. Students observe the tensions on the two sides of a belt, find the coefficient of friction for each belt section and study the effect of angle of lap. It is manufactured by JaincoLab.
Specifications
The apparatus has an aluminium alloy pulley of about 150 mm diameter graduated every 15 degrees, V, rope and flat belts and two load hangers, and measures 230 x 150 x 280 mm at about 10 kg excluding weights.
| Product | Machine Friction of Belts Apparatus |
| SKU | JA-AMLE-8944 |
| Mounting | Wall mounted |
| Pulley | Aluminium alloy, approx. 150 mm diameter, machined grooves for three belts, graduated at 15 degree intervals |
| Belts | V, rope and flat |
| Load hangers | 2 |
| Manual | Instruction manual for student and lecturer |
| Dimensions and weight (excluding weights) | 230 x 150 x 280 mm; 10 kg (approx.) |
Applications of the belt friction apparatus
By loading each side of the belt until it slips, students verify the belt tension ratio, compare V, rope and flat belts and see how a larger angle of lap raises the friction that can be transmitted.
- Ratio of tight side to slack side tension
- Coefficient of friction for V, rope and flat belts
- Effect of angle of lap
- Comparing belt sections for power transmission
- Applied mechanics and theory of machines practicals in B.Tech and diploma courses
Scope of supply and ordering
The listing covers the wall-mounted pulley, three belts, two load hangers and the instruction manual. A set of weights is confirmed on the quotation. Accessories, spares and quantities are confirmed on the quotation.
MOQ, lead time and packing for the Machine Friction of Belts Apparatus are confirmed on each quotation for the quantity and delivery destination. Single units for one laboratory and complete sets for institutions or training programmes are both supplied.
Frequently asked questions
Which belts are supplied?
V, rope and flat belts.
How is the angle of lap set?
The pulley is graduated at 15 degree intervals for setting and reading the lap angle.
What does the experiment determine?
Belt tensions, the coefficient of friction for each belt section and the effect of angle of lap.
