Three Stage Spur Gear Manufacturer,Supplier and Exporter in India
Product Code : JA-DOMLE-9138
The Three Stage Spur Gear (SKU JA-DOMLE-9138) is a gear-dynamics trainer in which a set of weights on a cable drum accelerates a spur gear train on four parallel shafts, so students can study motion sequences and the influence of rotational inertia. Coupling pins select different gear stages and flywheels can be added to each shaft. This three stage spur gear trainer is supplied by JaincoLab for theory of machines and machine design labs.
Specifications
The trainer has four parallel shafts carrying three drive wheels and three drive gears, a cable drum with a variable set of weights raised by a crank, a hand brake, a ratchet, a clamping-roller freewheel, attachable flywheels and a transparent cover with lock.
| Product | Three Stage Spur Gear |
| SKU | JA-DOMLE-9138 |
| Shafts | Four parallel shafts |
| Gearing | Three drive wheels and three drive gears; stages selected with coupling pins |
| Drive | Cable drum and variable set of weights, raised by crank |
| Braking and holding | Hand brake; ratchet to hold the weight |
| Freewheel | Clamping-roller freewheel |
| Flywheels | Attachable to each shaft |
| Cover | Transparent protective cover with lock |
| Dimensions and weights | Confirmed on the quotation |
Experiments on the three stage spur gear trainer
By releasing the weights and timing the motion, students relate the accelerating torque to angular acceleration through one, two or three gear stages and see how inertia on each shaft changes the result.
- Angular acceleration of a gear train under a known torque
- Effect of gear stage selection on speed and torque
- Influence of added flywheel inertia on each shaft
- Reduced moment of inertia of a multi-stage drive
- Theory of machines and machine dynamics practicals
Scope of supply and ordering
The listing covers the three-stage spur gear trainer with weights, cable drum, flywheels and cover as described above. Accessories, spares and quantities are confirmed on the quotation.
Packing, MOQ and lead time for the Three Stage Spur Gear are set on each quotation according to the order size and destination. Bulk orders for institutions and tender supplies, including export to Africa, the Middle East and South and South-East Asia, are handled.
Frequently asked questions
How is the gear train driven?
A variable set of weights on a cable drum accelerates the train; the weights are raised with a crank.
Can different gear stages be used?
Yes. Coupling pins connect the shafts to realise different stages.
Can inertia be changed?
Yes. A flywheel can be attached to each shaft.
Related products
Browse the full mechanical engineering lab equipment range from JaincoLab, including theory of machines and dynamics of machines apparatus.
Request a quote
Request the price and specification sheet for the Three Stage Spur Gear through the JaincoLab contact page; mention SKU JA-DOMLE-9138, the quantity and where it is to be delivered. Buying under a laboratory tender? Use our tenders page.
