Transistor Characteristics Apparatus Manufacturer,Supplier and Exporter in India
Product Code : JA-SCD-1079
The Jaincolab Transistor Characteristics Apparatus is used to study the input and output characteristics of common-base and common-emitter PNP and NPN transistors, with one of each transistor type mounted behind the panel. As a manufacturer and exporter of Scientific Instrument equipment based in Ambala, Haryana, Jaincolab supplies this transistor characteristics apparatus to educational and industrial laboratories across India.
The instrument consists of two D.C. regulated power supplies, 0-10V D.C./500mA/50mA and 0-1V D.C./30mA, with four round meters for voltage and current measurement. One PNP and one NPN transistor are mounted behind the panel, and connections for the supplies and transistors are brought out on terminals. The panel measures 15" x 8" x 4".
Specifications
| Parameter | Specification |
|---|---|
| Activity | Input and output characteristics of common-base and common-emitter PNP and NPN transistors |
| Power Supply 1 | 0-10V D.C., 500mA/50mA |
| Power Supply 2 | 0-1V D.C., 30mA |
| Meters | Four round meters, for voltage and current measurement |
| Transistors | One PNP and one NPN transistor mounted behind the panel |
| Dimensions | 15" x 8" x 4" |
Key Features
- Studies both common-base and common-emitter input/output characteristics of PNP and NPN transistors
- Two D.C. regulated power supplies for flexible biasing across ranges
- Four round meters for direct voltage and current readings
- Mounted PNP and NPN transistors with all connections on terminals
Why Choose Jaincolab
Jaincolab (Jain Scientific Suppliers, Ambala, Haryana) has manufactured and supplied laboratory and electronic measuring instruments, including the Transistor Characteristics Apparatus, for school, college and university electronics laboratories across India and internationally since 1982. Jain Scientific Suppliers holds ISO 9001:2015 (quality management) and ISO 14001:2015 (environmental management) certification for its manufacturing operations.
Explore related Scientific Instrument equipment from Jaincolab:
- H Parameters of PNP Transistor in Common Emitter Mode
- FET Characteristics Apparatus
- SCR Characteristics Apparatus
- Scientific Instrument category
Applications
| Application Area | Typical Use |
|---|---|
| Electronics Laboratory | Plotting input and output characteristics of BJTs in common-base and common-emitter modes |
| Semiconductor Device Education | Teaching PNP and NPN transistor operation to students |
Frequently Asked Questions
Q: What does this apparatus study?
A: It studies the input and output characteristics of common-base and common-emitter PNP and NPN transistors.
Q: Which transistors are included?
A: One PNP and one NPN transistor are mounted behind the panel.
Q: What power supplies does it include?
A: Two D.C. regulated power supplies, 0-10V/500mA/50mA and 0-1V/30mA.
Q: Is a technical datasheet available before ordering?
A: Full specifications are confirmed at the time of quotation; contact Jaincolab with your requirement for written confirmation.
Q: Is Jaincolab a certified manufacturer?
A: Jain Scientific Suppliers holds ISO 9001:2015 (quality management) and ISO 14001:2015 (environmental management) certification for its manufacturing operations.
Request a Quote
For pricing, lead times and technical clarification on this instrument, contact Jaincolab directly. Request a Quote and our team will confirm specifications and availability for your institution.
