Zero Voltage Switching

Product Code : JA-PET-1444

Zero Voltage Switching

  • Power Electronic Training Board has been designed specifically for the study of Zero voltage switching board.
  • Practical experience on this board carries great educative value for Science and Engineering Students.

Object:

  • To study operation of zero voltage switching of thyristor

Features:

The board consists of the following built-in parts:

  • A transformer to give low AC voltage to Thyristor and DC voltage to transistor
  • Two diode used as fullwave rectifier
  • One diode to avoid –ve voltage to collector of NPN transistor
  • A NPN transistor
  • A Thyristor
  • Adequate no. of other Electronic Components
  • Mains ON/OFF switch, Fuse and Jewel light
  • The unit is operative on 230V ±10% at 50Hz A.C. Mains
  • Good Quality, reliable terminal/sockets are provided at appropriate places on panel for connections/ observation of waveforms
  • Strongly supported by detailed Operating Instructions, giving details of Object, Theory, Design procedures, Report Suggestions and Book References

Weight:

  • 3 Kg. (Approx.)

Dimension:

  • W 340 x H 110 x D 210

Other Apparatus Required:

  • Digital Multimeter - Order Code 16901
  • Dual Trace Cathode Ray Oscilloscope 20MHz (Unearthed/with isolation transformer for unearthing)
