Fluidisation and Fluid Bed Heat Transfer Unit Manufacturer,Supplier and Exporter in India
Product Code : JA-CELE-9117
The Fluidisation and Fluid Bed Heat Transfer Unit (SKU JA-CELE-9117) is a bench unit for investigating air flow through fixed and fluidised beds and for measuring heat transfer rates and coefficients from a heated surface in the bed. The bed sits in a transparent glass chamber, the supplied bed materials can be changed quickly, and other granular materials and air distributors can be used for project work. This fluidised bed heat transfer unit is supplied by JaincoLab for chemical engineering and heat transfer laboratories.
Specifications
The unit uses air as the fluidising medium, with a glass bed chamber, an electric heater fed through a variable transformer, a voltmeter (0-250 V) and ammeter (0-3 A), air flow meters of 0.15 to 3.5 litres/sec, a digital thermometer and a manometer for bed pressure drop.
| Product | Fluidisation and Fluid Bed Heat Transfer Unit |
| SKU | JA-CELE-9117 |
| Fluidising medium | Air |
| Bed chamber | Glass, transparent, with changeable bed materials |
| Heater | Electric, power set by variable transformer |
| Heater power metering | Voltmeter 0-250 V, ammeter 0-3 A |
| Air flow meters | 0.15 to 3.5 litres/sec |
| Temperatures | Digital thermometer for heater surface, air inlet and probe |
| Pressure drop | Manometer across the bed |
| Base and protection | Glass reinforced plastic base; fusing and earthing of components; heater temperature controller |
Experiments with the fluidised bed heat transfer unit
Students raise the air flow from a packed bed to full fluidisation, recording pressure drop and bed behaviour, then measure heat transfer from the heater at different conditions.
- Observing granular materials from the onset of fluidisation to entrainment
- Air flow and pressure drop through packed and fluidised beds
- Effect of distributor design on bed behaviour
- Effect of superficial velocity, depth of immersion and particle size on heat transfer
- Comparing fluid bed and convective heat transfer coefficients in air
Scope of supply and ordering
This listing covers the fluidisation and fluid bed heat transfer unit with glass chamber, heater, instruments and the supplied range of bed materials. The air supply arrangement and any additional bed materials are also confirmed on the quotation.
Frequently asked questions
What does the unit investigate?
Air flow through fixed and fluidised beds and heat transfer rates and coefficients from a heated surface.
What is the air flow range?
The flow meters cover 0.15 to 3.5 litres/sec.
Can other bed materials be used?
Yes, locally sourced granular materials and alternative air distributors can be used for project work.
