Kaplan Turbine Test Rig Manufacturer,Supplier and Exporter in India
Product Code : JA-HLE-8979
The Kaplan Turbine Test Rig (SKU JA-HLE-8979) is a Kaplan turbine test rig that shows the construction and working of this axial flow reaction turbine and measures its performance. Input is measured with a pressure gauge and orifice meter, and output with a rope brake dynamometer on a 300 mm drum. It is rated 5 HP at 1500 rpm, with 4500 litres per minute discharge at 7 m supply head and gun metal aerofoil guide vanes. It is manufactured by JaincoLab.
Specifications
The rig is rated 5 HP at 1500 rpm, takes 4500 litres/minute at 7 m supply head, has gun metal aerofoil guide vanes and cast iron construction, and measures input by pressure gauge and orifice meter and output by rope brake.
| Product | Kaplan Turbine Test Rig |
| SKU | JA-HLE-8979 |
| Type | Kaplan (reaction) turbine |
| Capacity | 5 HP |
| Rated speed | 1500 rpm |
| Discharge capacity | 4500 litres/minute |
| Supply head | 7 m |
| Guide vanes | Gun metal, aerofoil blade shaped |
| Input measurement | Pressure gauge and orifice meter |
| Output measurement | Rope brake dynamometer |
| Material and drum | Cast iron; 300 mm diameter drum |
Applications of the Kaplan turbine test rig
The rig lets students test a low head, high flow turbine and compare its characteristics with Pelton and Francis turbines, completing the hydraulic turbine series in the lab.
- Performance test of a Kaplan turbine
- Input power from pressure gauge and orifice meter
- Brake power by rope brake dynamometer
- Efficiency curves at constant head
- Hydraulic machines practicals in B.Tech, diploma and AMIE courses
Scope of supply and ordering
The listing covers the Kaplan turbine with orifice meter, pressure gauge and rope brake dynamometer as described. The supply pump and sump are confirmed on the quotation.
Each quotation confirms the MOQ, lead time and packing for this item against the quantity ordered and the delivery destination. Orders for a single laboratory as well as multi-laboratory sets for new institutions are supplied.
Frequently asked questions
What head and flow does it use?
A 7 m supply head and a discharge of 4500 litres per minute.
What is the rated output?
5 HP at 1500 rpm.
How are input and output measured?
Input by pressure gauge and orifice meter; output by rope brake dynamometer.
Related products
- Francis Turbine Test Rig
- Pelt on Wheel Turbine Test Rig
- Hydraulic Ram Test Rig
- Reciprocating Pump Test Rig
See the complete mechanical engineering laboratory range for engineering colleges, polytechnics and ITIs.
Request a quote
To order the Kaplan Turbine Test Rig, send the quantity and delivery destination through the JaincoLab contact page or email [email protected], quoting SKU JA-HLE-8979. Institutions and contractors buying under a tender can also reach us via the tenders page.
