Bernoulli Theorem Apparatus Manufacturer,Supplier and Exporter in India
Product Code : JA-HLE-8973
The Bernoulli Theorem Apparatus (SKU JA-HLE-8973) is a Bernoulli theorem apparatus for verifying Bernoulli's equation along a converging-diverging duct. Water flows from acrylic constant head tanks through a 300 mm differential venturi machined from acrylic square bar, with piezometer readings along its length. It has a 100 litre PVC storage tank, a mono-block pump, a 25 litre rotomoulded measuring tank, PVC piping with valves and a digital stop watch. It is manufactured by JaincoLab.
Specifications
The apparatus uses a 300 mm acrylic differential venturi, two acrylic constant head tanks on a stand, a 100 L PVC storage tank, a single phase mono-block pump, a 25 L measuring tank and PVC piping; the listed pump rating conflicts (0.25 HP and 1/2 HP) and is confirmed on the quotation.
| Product | Bernoulli Theorem Apparatus |
| SKU | JA-HLE-8973 |
| Test section | Differential venturi, 300 mm long, acrylic square bar |
| Constant head tanks | 2, acrylic, mounted on stand |
| Storage tank | PVC, 100 litres (approx.) |
| Pump | Single phase mono-block; rating confirmed on the quotation |
| Measuring tank | 25 litres, rotomoulded |
| Piping | PVC with valves |
| Accessory | Digital stop watch |
| Services required | Single phase 200/220 V; water to fill the sump |
Applications of the Bernoulli theorem apparatus
Students record piezometric heads at points along the venturi at a measured flow rate, then add velocity head to show that total head stays nearly constant, as Bernoulli's equation predicts.
- Verification of Bernoulli's theorem
- Pressure head and velocity head along a venturi
- Total energy line and hydraulic gradient
- Flow measurement with the measuring tank and stop watch
- Fluid mechanics practicals in B.Tech, diploma and B.Sc courses
Scope of supply and ordering
The listing covers the Bernoulli apparatus with venturi, constant head tanks, storage and measuring tanks, pump, piping and stop watch as listed. Accessories, spares and quantities are confirmed on the quotation.
There is no fixed MOQ on this listing: minimum quantity, lead time and packing are stated on the quotation for your order size and destination. Bulk college, polytechnic and tender orders are supplied.
Frequently asked questions
What is the test section?
A 300 mm differential venturi made from acrylic square bar.
What tanks are included?
Two acrylic constant head tanks, a 100 L PVC storage tank and a 25 L measuring tank.
What pump rating is fitted?
The product data lists both 0.25 HP and 1/2 HP; the rating is confirmed on the quotation.
