Axial Flow Pump Test Rig Manufacturer,Supplier and Exporter in India
Product Code : JA-HLE-8982
The Axial Flow Pump Test Rig (SKU JA-HLE-8982) is an axial flow pump test rig for studying the characteristics of an axial flow pump. The pump discharges about 150 litres per minute and is driven by a 3 HP three phase motor, with an electrical panel carrying a switch and an energy meter to measure input power. Sump and measuring tanks are in M.S. with FRP lining or in S.S., and the piping has a pressure relief valve, gate valve and pressure gauge. It is manufactured by JaincoLab.
Specifications
The rig has an axial flow pump of about 150 LPM on a 3 HP, 400/440 V three phase motor, an energy meter for input power, M.S./FRP or S.S. sump and measuring tanks, and piping with relief valve, gate valve and gauge.
| Product | Axial Flow Pump Test Rig |
| SKU | JA-HLE-8982 |
| Pump | Axial flow, discharge about 150 LPM |
| Motor | 3 HP, three phase, 400/440 V AC |
| Electrical panel | Switch and energy meter for input power |
| Sump tank | M.S. with FRP lining or S.S., suitable size for independent circulation |
| Measuring tank | M.S. with FRP lining or S.S., with standard fittings |
| Piping | Pipes, pressure relief valve, gate valve, fittings, pressure gauge |
Applications of the axial flow pump test rig
Students throttle the delivery, record head, discharge and energy meter readings, and plot the characteristic curves of an axial flow pump to compare with centrifugal pump behaviour.
- Head against discharge characteristics
- Input power by energy meter
- Overall efficiency of an axial flow pump
- Comparison with centrifugal pump curves
- Hydraulic machines practicals in B.Tech, diploma and AMIE courses
Scope of supply and ordering
The listing covers the axial flow pump test rig with motor, panel, sump and measuring tanks and piping. The tank material (M.S./FRP or S.S.) is chosen on the order.
Frequently asked questions
What discharge does the pump give?
About 150 litres per minute.
What motor and supply are needed?
A 3 HP three phase motor on a 400/440 V AC supply.
How is input power measured?
With an energy meter on the electrical panel.
