Batch Distillation Pilot Plant Manufacturer,Supplier and Exporter in India
Product Code : JA-CELE-9499
The Batch Distillation Pilot Plant (SKU JA-CELE-9499) is a compact sieve-tray batch distillation unit for chemical engineering mass transfer practicals. A 600 mm column with 7 sieve trays stands on a 3 litre reboiler with a 1600 W heater under thyristor control, and a condenser with reflux head returns liquid at a ratio set by two programmable timers. Six digital thermometers follow the temperature profile. This sieve tray batch distillation plant is supplied by JaincoLab for engineering colleges and polytechnics.
Specifications
The plant has a 600 mm column with 7 sieve trays, a 3 litre reboiler with 1600 W heater, a condenser with reflux head, stainless steel tube-in-tube heat exchangers, a 1 litre distillate tank and a glass and stainless steel variable-area flow meter of 20-200 litres/hour.
| Product | Batch Distillation Pilot Plant |
| SKU | JA-CELE-9499 |
| Column | Height 600 mm, 7 sieve trays |
| Reboiler | 3 litres, 1600 W electric heater, thyristor power control |
| Condenser | With reflux head; 2 programmable timers for reflux ratio |
| Distillate tank | 1 litre |
| Heat exchangers | Tube-in-tube, stainless steel |
| Temperature | 6 digital thermometers, probes in stainless steel sleeves |
| Flow meter | Variable-area, glass and stainless steel, 20-200 litres/hour |
| Safety control | Emergency stop button |
Experiments with the sieve tray batch distillation plant
Students distil a binary mixture batchwise, compare total-reflux and set-reflux runs and relate distillate composition to the tray temperature profile.
- Batch distillation of binary mixtures
- Effect of reflux ratio on distillate composition
- Total reflux operation and tray efficiency
- Temperature profile along a sieve tray column
- Mass transfer operations practicals in B.Tech/B.E. chemical engineering
Scope of supply and ordering
This listing covers the batch distillation pilot plant with column, reboiler, condenser, heat exchangers, thermometers, flow meter and control panel. Cooling water connection and power supply are also confirmed on the quotation.
The Batch Distillation Pilot Plant can be ordered for a single laboratory or as part of a complete laboratory package for a college or training programme.
Frequently asked questions
What trays does the column use?
Seven sieve trays in a 600 mm column.
What is the reboiler capacity?
3 litres, with a 1600 W electric heater under thyristor control.
What reflux ratio control is provided?
Two programmable timers set the reflux ratio at the reflux head.
