Training Board for MOSFET

Product Code : JA-AET-1467

Characteristics of MOSFET

Object:

  • To determine experimentally the Drain characteristics of a given MOSFET
  • To study the use of MOSFET as an amplifier and to measure its voltage gain in common source configuration

Features:

The board consists of following built-in parts:

  • 0-15V D.C. at 50mA, continuously variable regulated Power Supply
  • 0-4V D.C. at 10mA, continuously variable regulated Power Supply
  • 0-1V D.C. at 10mA, continuously variable regulated Power Supply
  • Metal Oxide Semiconductor Field Effect Transistor (MOSFET)
  • Adequate no. of other electronic components
  • Mains ON/OFF switch, Fuse and Jewel light
  • The unit is operative on 230V ±10% at 50Hz A.C. Mains
  • Adequate no. of patch cords stackable from rear both ends 4mm spring loaded plug length ½ metre
  • Good Quality, reliable terminal/sockets are provided at appropriate places on panel for connections/ observation of waveforms
  • Strongly supported by detailed Operating Instructions, giving details of Object, Theory, Design procedures, Report Suggestions and Book References

Other Apparatus Required:

  • Audio Frequency Generator
  • A.C. Milli voltmeter
  • Cathode Ray Oscilloscope 20MHz
  • Digital Voltmeter DC 3½ Digit range of 20V
  • Digital Current meter DC 3½ Digit range of 20mA
