Advanced Measuring Equipment for Electrical Experiments Manufacturer,Supplier and Exporter in India
Product Code : SCL-LEP-12421
TRMS digital multimeter, IP67:
6000-point multimeter
Measurement ranges
V AC/DC: 6V to 1000V
A AC/DC: 600µA to 10A
R: 600 Ohm to 60Mohm
Capacitance: 60 nF to 6000 µF
Frequency: 9.999Hz to 9.999kHz
T: -20° to +780°C
Continuity test
Diode test
Category: CAT III 1000V; CAT IV 600V; Protection class IP67; Standards: EN 61010-1
TRMS digital multimeter:
Digital and analog (barograph) display
50,000-point multimeter
Integrated data logger with graphic display
Measurement ranges
TRMS
V AC/DC: 500mV to 1000V
A AC/DC: 500µA to 10A
R: 500 ohms to 50Mohm
Capacitance: 5 nF to 10000 µF
Frequency 9 Hz to 10 MHz
T: -200° to +1350°C
Continuity test
Diode test
Connecting wire:
Connecting wire 4 mm with reverse side, 250 mm, blue
Connecting wire 4 mm with backbox, 250 mm, red
Connecting wire 4 mm with backbox, 250 mm, yellow
Connecting wire 4 mm with backbox, 750 mm, blue
Connecting lead 4 mm with backbox, 750 mm, red
Connecting wire 4 mm with backplane, 750 mm, yellow
Low-voltage power supply with dual digital display, 6-12V/5A and 0-12Vdc.
DC output voltage: 0 to 12V with green LED for voltage regulation
DC output currents: 3 ranges, 25mA, 250mA to 2.5A, red LED for current regulation
AC output voltages: 6 & 12V
AC output current: 5A
Digital voltmeter with DC voltage display: 3 x 14 mm digits, 100mV resolution
Digital ammeter with DC current display: 3-digit, 14 mm, resolution 100µA over 25mA, 1mA over 250mA and 10mA over 2.5A
Outputs: 4mm safety sockets
Protection: against short-circuit and overcurrent by built-in thermal circuit breakers (automatic reset after fault clearance) and 5A/250V and 15A/250V fuses
Made in EUROPE (Eliminatory Criteria)
Weight: 4.2 kg
Dimensions: 238x218x90 mm
50MHz digital oscilloscope - 2 channels, 1GS/s specially designed for teaching purposes:
7" WVGA color display
32 automated measurements
Dual-window FFT with simultaneous time and frequency domain views
Trigger frequency counter, pan and zoom capability
Innovative integrated tutorial system with lab exercises and step-by-step instructions for students
Hz - 5 MHz function generator with power output on 4 mm connectors
Range: 0.01Hz to 5MHz
High signal quality
50 Ohm and TTL output protected up to ±60 V
Internal or external 50 MHz reciprocal frequency meter
0.5 Ohms output delivering 15 W into 4 Ohms protected (against short-circuits)
BNC shielded cable, l=750 mm
BNC socket to 4mm plug adapter
BNC plug/4mm socket adapter
BNC-type T-connector
10x 10 Ohm single-stage resistor box
33 Ohm rheostat, max 3.1A with 4 mm terminals
Capacitance decade boxes:
5 capacity steps
1% accuracy
100 pF to 11.111 µF
Low temperature coefficient capacitors
Maximum voltage 300 V= or 230 V~ 50 Hz.
Equipped with safety sockets
Robust switches
Inductance decade box:
7 inductance decades
5% accuracy
1 µH to 11.111110 H
Q factor from 55 to 100 depending on decade
Equipped with safety sockets
Intermediate socket for each decade
Robust switches
