Fibre Optic Trainer for Numerical Aperture Manufacturer,Supplier and Exporter in India
Product Code : JA-FOT-1540
This fibre optic trainer for numerical aperture is built around 660 nm and 850 nm analogue transmitters, a phototransistor receiver and PMMA fibre, with an NA jig, NA scale and mandrel for measurement work. The listed objects cover the transmitter and receiver, numerical aperture of PMMA fibre, loss in 1 m and 5 m patch cords, E-O and O-E converter characteristics and an intensity modulation system (SKU JA-FOT-1540).
Specifications
Parts and ratings in the listing:
| Product | Fibre Optic Trainer for Numerical Aperture |
| SKU | JA-FOT-1540 |
| Sources | Analogue transmitters at 660 nm and 850 nm, switch-selected (SPDT) |
| Detector | Fibre-optic receiver with phototransistor |
| Patch cords | PMMA fibre, 1 m and 5 m, with in-line SMA adaptor |
| Measurement aids | NA jig with length scale, NA scale for the LED spot width, mandrel |
| Adjustments | LED forward-current and phototransistor-current potentiometers |
| Supply | IC-regulated DC supply; 230 V ±10%, 50 Hz mains |
| Weight and size | 3 kg approx.; W 340 x H 110 x D 210 (as listed) |
| Also required | AF/RF generator 10 Hz to 1 MHz, digital fibre-optic power meter, digital multimeter, 20 MHz oscilloscope |
Listed objects
Work covered by the trainer:
- Fibre-optic transmitter and receiver
- Numerical aperture of PMMA fibre
- Loss in 1 m and 5 m PMMA patch cords
- Electrical-to-optical and optical-to-electrical converter characteristics
- Intensity modulation system
Scope of supply and ordering
Supplied by JaincoLab, the listing covers the trainer with its transmitters, receiver, patch cords, adaptor, NA jig, scale and mandrel; the generator, power meter, multimeter and oscilloscope are quoted separately if required. Lead time and packing depend on the order size and are confirmed when we quote.
Frequently asked questions
Why are two fibre lengths supplied?
Comparing the 1 m and 5 m PMMA patch cords lets students work out the loss in the fibre.
Which wavelengths are available?
660 nm and 850 nm, chosen with an SPDT switch.
Which instruments must be added?
An AF/RF generator (10 Hz to 1 MHz), a digital fibre-optic power meter, a digital multimeter and a 20 MHz oscilloscope.
