Flow Table Manufacturer,Supplier and Exporter in India
Product Code : JA-M-8902
The Flow Table (SKU JA-M-8902) measures the workability of fresh concrete by the flow test. A conical mould is filled and lifted off, and the table is then raised and dropped 12.5 mm repeatedly by a ground and hardened steel cam, so the concrete spreads; the increase in diameter gives the flow. The flow table for concrete is worked by a hand wheel or, in the electrically operated version, by a motor through a reduction gear at about 100 rpm. It is made by JaincoLab.
Specifications
The table top is 76.2 cm (30 in) in diameter with integral cast ribs, and each cam cycle drops it 12.5 mm; the motorised version runs on 230 V single-phase supply.
| Product | Flow Table |
| SKU | JA-M-8902 |
| Table top | 76.2 cm (30 in) dia., cast iron with integral ribs, finely machined |
| Drop | 12.5 mm per cam cycle; ground and hardened steel cam |
| Drive | Hand wheel (manual) or motor with reduction gear, about 100 rpm |
| Conical mould | 12 cm high, 17 cm top i.d., 25 cm base i.d., with handles |
| Tamping rod | 16 mm dia. x 600 mm, one end rounded |
| Power (motorised) | 230 V, single-phase, 50 Hz AC |
Applications of the flow table for concrete
The flow test suits wetter concrete mixes where the slump test gives little information, and results guide adjustments to water and admixture content.
- Workability of fresh concrete by the flow test
- Comparing mixes with different water or admixture content
- Concrete technology practicals in civil engineering courses
- Site and college materials testing laboratories
Scope of supply and ordering
The listing covers one flow table, manual or motorised, with conical mould and tamping rod, from JaincoLab; the version is confirmed on the quotation. Accessories, spares and quantities are confirmed on the quotation.
MOQ, lead time and packing are confirmed on each quotation for the quantity and delivery destination. Tables are supplied singly or with concrete testing sets for colleges and tender orders.
Frequently asked questions
What is the table diameter?
76.2 cm (30 inches).
How far does the table drop?
12.5 mm per cam cycle.
Is it manual or motorised?
Both versions are listed: hand wheel, or motor at about 100 rpm on 230 V single-phase.
Related products
Concrete and cement testing equipment is grouped in the Materials range; chemistry apparatus is in the chemistry lab equipment catalogue.
Request a quote
To request a quotation for the Flow Table, send the quantity and the delivery destination through the JaincoLab contact page or email [email protected], quoting SKU JA-M-8902. Buying under a laboratory tender? Use our tenders page.
