Laboratory Heat Sealer Manufacturer,Supplier and Exporter in India
Product Code : JA-LS-5109
The Laboratory Heat Sealer (SKU JA-LS-5109) is a pneumatic machine made by JaincoLab for making heat seals on thermoplastic and packaging materials under controlled conditions. A constantly heated sealing bar or die presses the materials together along a set contact path, using heat and pressure to weld the thermoplastic layers. Force, temperature and dwell time are all adjustable, so seals can be made repeatably when films, foils and adhesives are being evaluated.
Specifications
The values and features below are from the listing.
| Product | Laboratory Heat Sealer |
| SKU | JA-LS-5109 |
| Operation | Fully pneumatic |
| Control | Microprocessor based, digital display |
| Temperature control | P.I.D. controller (imported, as listed); upper and lower jaws can be set to different temperatures |
| Sealing force | Adjustable, 15 to 180 kg |
| Dwell time | 0.0 to 9.9 seconds |
| Jaw patterns | Plain, straight line, diamond knurling |
| Sealing length options | 150 mm, 300 mm, 500 mm |
Applications of the laboratory heat sealer
The listing names these uses:
- Heat sealing films and foils
- Sealing heat seal connectors and plastic ports
- Testing thermally activated adhesives
Scope of supply and ordering
Choose the sealing length and jaw pattern when you ask for a quotation; the machine configuration, quantities and packing are confirmed on it.
Frequently asked questions
What sealing force can be applied?
It is adjustable from 15 to 180 kg.
Which jaw patterns are available?
Plain, straight line and diamond knurling.
Can the two jaws run at different temperatures?
Yes. The upper and lower jaws can be set to different temperatures.
Related products
Other instruments are listed in the JaincoLab lab supplies range.
Request a quote
Send the sealing length and jaw pattern you need for the Laboratory Heat Sealer (JA-LS-5109) through our contact page. Tender and project enquiries can be sent through the tenders page.
