LCR Impedance Circuit Manufacturer,Supplier and Exporter in India
Product Code : JA-VOVLACOS-1110
The LCR Impedance Circuit (SKU JA-VOVLACOS-1110) is used to calculate the AC power factor of an LCR circuit connected in series across an AC voltage. One resistance, one capacitor and one inductance are connected in series, a 100 V AC supply is selected with a band switch, and two AC moving-coil meters read voltage and current; all connections are brought out to terminals so the voltage across each element can be measured.
Specifications
The listing gives these details:
| Product | LCR Impedance Circuit |
| SKU | JA-VOVLACOS-1110 |
| Power supply | AC, 100 V, band switch selection |
| Meters | Two AC moving-coil meters, voltage and current |
| Circuit | One resistance, one capacitor and one inductance in series |
| Connections | Terminals |
| Size | 10 x 8 x 4 in |
Scope of supply and ordering
One apparatus per order line. Quantities and packing are confirmed on the quotation.
Frequently asked questions
What is calculated with the LCR Impedance Circuit?
The AC power factor of a series LCR circuit.
Which components are in the circuit?
One resistance, one capacitor and one inductance, connected in series.
