Magnetic Plotting Compass (Transparent) Manufacturer,Supplier and Exporter in India
Product Code : JC-SL-4640
The transparent plotting compass (SKU JC-SL-4640) is a small magnetic compass for tracing field patterns in magnetism and electromagnetism experiments. Its needle sits in a metal case that is clear on both faces, so the compass can be placed on an overhead projector and the needle direction shown to a whole class on the screen.
Specifications
The case material, the two-sided transparency and the intended experiments are the listed details.
| Product | Magnetic Plotting Compass (Transparent) |
| SKU | JC-SL-4640 |
| Case | Metal |
| Faces | Transparent on both sides |
| Suitable for | Overhead projector demonstrations |
| Used in | Magnetic and electromagnetic experiments |
Applications of the transparent plotting compass
- Plotting the field lines around a bar magnet, step by step
- Showing the field around a current-carrying wire or coil
- Projecting the needle direction to the class with an overhead projector
Scope of supply and ordering
The item is a single plotting compass; class sets are quoted by number of pieces. Packing and dispatch time appear on the quotation.
Frequently asked questions
Can this plotting compass be used on an overhead projector?
Yes. The case is transparent on both sides, so the needle shows on the projection screen.
How is it different from the standard magnetic plotting compass?
This version is transparent on both faces for projection; the standard plotting compass has a scale printed inside the base and a glass top, in 1, 1.5 and 2 in diameters.
