Q Meter Manufacturer,Supplier and Exporter in India
Product Code : JA-TAMI-1018
The Q Meter (SKU JA-TAMI-1018) measures the quality factor, Q, of an inductor, a value that has to be known when coils and transformers are designed. The coil is connected, the measuring frequency is set to 1 kHz or 10 kHz, and the balancing dial, calibrated directly in Q, is turned against the moving-coil meter. Readings cover 0.1 to 100. The bench case measures 14 x 9 x 5.5 inches and runs from 220 V, 50 Hz.
Specifications
Range, frequencies and build from the product data:
| Product | Q Meter |
| SKU | JA-TAMI-1018 |
| Measured quantity | Quality factor (Q) of inductors |
| Range | 0.1 to 100 |
| Measuring frequency | 1 kHz or 10 kHz |
| Indicator | Moving-coil meter with balancing dial calibrated in Q |
| Supply | 220 V, 50 Hz |
| Size | 14 x 9 x 5.5 in |
Practical uses
- Measuring the Q of coils wound for tuned-circuit and filter experiments
- Comparing inductors with different cores and windings during coil design
- Checking transformer windings before use in circuit practicals
- Studying how Q changes between the 1 kHz and 10 kHz test frequencies
Scope of supply and ordering
The Q meter is supplied as one bench instrument per order line. Test coils, quantities and packing are listed on the quotation.
Frequently asked questions
What does the Q Meter measure?
The quality factor (Q) of an inductor, from 0.1 to 100.
At what frequencies can the measurement be made?
At 1 kHz or 10 kHz.
How is the reading taken?
By turning the balancing dial, which is calibrated directly in Q, against the moving-coil meter.
Related products
Component measuring instruments are listed in our scientific instrument range.
Request a quote
Request the Q Meter through our contact page, stating the quantity. Buying under a laboratory tender? Use our tenders page.
