PN Junction and Zener Diode Characteristics Apparatus Forward and Reverse V-I Characteristics Manufacturer,Supplier and Exporter in India
Product Code : JA-SCD-1085
The PN Junction and Zener Diode Characteristics Apparatus (SKU JA-SCD-1085) is used to plot the forward and reverse V-I characteristics of both a PN junction diode and a Zener diode on one unit, so the ordinary diode and the Zener breakdown can be compared. Two independent DC power supplies and two double-range meters are built in, and both diodes are mounted on the panel with terminal connections.
Specifications
The listing gives these details:
| Product | PN Junction and Zener Diode Characteristics Apparatus Forward and Reverse V-I Characteristics |
| SKU | JA-SCD-1085 |
| Diodes | PN junction diode and Zener diode, on panel |
| Power supplies | Two independent DC supplies |
| Meters | Two double-range meters |
| Connections | Terminals |
| Size | 15 x 8 x 4 in |
Scope of supply and ordering
One apparatus per order line. Quantities and packing are confirmed on the quotation.
Frequently asked questions
Which diodes does this apparatus cover?
A PN junction diode and a Zener diode, both mounted on the panel.
What supplies and meters are built in?
Two independent DC power supplies and two double-range meters.
