Potentiometer Dial Pattern Manufacturer,Supplier and Exporter in India
Product Code : JA-SI-8121
The Potentiometer Dial Pattern (SKU JA-SI-8121) is a compact potentiometer for introducing students to e.m.f. measurement. Coarse steps come from 10, 14 or 22 coils arranged on a rotary dial, and the fine reading from a 50 cm linear slide wire divided into 500 equal parts. A thick knife-edge jockey makes contact on the slide wire.
Specifications
Details from the product data:
| Product | Potentiometer Dial Pattern |
| SKU | JA-SI-8121 |
| Dial coils | 10, 14 or 22 coils on a rotary dial |
| Slide wire | 50 cm, 500 equal divisions |
| Jockey | Thick knife-edge |
| Panel terminals | Battery, galvanometer, test circuits |
Scope of supply and ordering
State whether you need the 10-, 14- or 22-coil dial when you enquire; quantities and packing are confirmed on the quotation.
Frequently asked questions
How many dial coils does the dial pattern potentiometer have?
It is listed with 10, 14 or 22 coils on the rotary dial.
How finely can the slide wire be read?
The 50 cm slide wire is divided into 500 equal parts.
Related products
Potentiometers for e.m.f. measurement are listed in the scientific instrument range.
Request a quote
For the dial pattern potentiometer, send the coil option and quantity through the contact page. Tender and project enquiries can be sent through the tenders page.
