To Verify Switch Debouncer Manufacturer,Supplier and Exporter in India
Product Code : JA-DEECP-1193
The To Verify Switch Debouncer apparatus (SKU JA-DEECP-1193) shows how contact bounce from a mechanical switch is removed before the signal reaches digital logic. An IC 7400 quad 2-input NAND gate is used as a latch, driven by one SPDT switch. Two LEDs show the debounced outputs, and sockets are provided so the output voltage can be measured with a meter.
Specifications
The listing gives these details:
| Product | To Verify Switch Debouncer |
| SKU | JA-DEECP-1193 |
| IC | 7400, quad 2-input NAND |
| Input | One SPDT switch |
| Output indication | Two LEDs for the debounced outputs |
| Measurement | Sockets for the output voltage |
Scope of supply and ordering
Supply details, quantities and packing are confirmed on the quotation.
Frequently asked questions
How does the apparatus remove switch bounce?
The IC 7400 NAND gates form a latch that is set or reset cleanly by the SPDT switch.
Can the output voltage be measured?
Yes, sockets are provided for measuring it.
