Characteristics and Applications Thyristors Manufacturer,Supplier and Exporter in India
Product Code : JA-SCD-1095
The Characteristics and Applications Thyristors apparatus (SKU JA-SCD-1095) covers four devices on one panel: the Diac, Triac, UJT and SCR, with their supporting components. Three DC supplies are built in, 0-15 V at 150 mA, 0-50 V at 100 mA and 0-2.5 V at 200 mA, with four dual-range meters, and the supplies, meters and components are brought out to terminals for wiring each characteristic or application circuit.
Specifications
The listing gives these details:
| Product | Characteristics and Applications Thyristors |
| SKU | JA-SCD-1095 |
| Devices | Diac, Triac, UJT and SCR with supporting components |
| DC supply 1 | 0-15 V, 150 mA |
| DC supply 2 | 0-50 V, 100 mA |
| DC supply 3 | 0-2.5 V, 200 mA |
| Meters | Four dual-range meters |
| Size | 15 x 8 x 4 in |
Scope of supply and ordering
One apparatus per order line. Quantities and packing are confirmed on the quotation.
Frequently asked questions
Which devices does the thyristor apparatus cover?
The Diac, Triac, UJT and SCR, with supporting components.
What supplies are built in?
0-15 V DC at 150 mA, 0-50 V DC at 100 mA and 0-2.5 V DC at 200 mA.
